VL101G

GNSS Vehicle Terminal

The VL101G is a 4G vehicle tracker with GNSS positioning technology and dual-frequency GPS, ideal for a wide range of deployments where real-time location and accurate positioning are key. LTE communication with GSM (2G) fallback ensures a solid connection in almost all cases, and the inertial navigation system (INS) provides accurate information about your car’s movements even in areas with weak GPS signals. Moreover, driving behavior analysis, ignition detection and remote engine cut-off will make the VL101G a valuable part of your fleet management strategy.

VL101G
GNSS Vehicle Terminal

The VL101G is a 4G vehicle tracker with GNSS positioning technology and dual-frequency GPS, ideal for a wide range of deployments where real-time location and accurate positioning are key. LTE communication with GSM (2G) fallback ensures a solid connection in almost all cases, and the inertial navigation system (INS) provides accurate information about your car’s movements even in areas with weak GPS signals. Moreover, driving behavior analysis, ignition detection and remote engine cut-off will make the VL101G a valuable part of your fleet management strategy.

FEATURES
SPECIFICATIONS
DOWNLOADS
GPS & BDS Positioning、Support GPS, IRNSS, GLONASS、GPS & LBS Positioning
GPS/BDS/GLONASS/Galileo Positioning
A synergy of multiple positioning systems ensures that locations are accurately displayed on the cloud platform.
Dual-Frequency GPS
Dual-Frequency GPS
More stable connection, more accurate position, and higher resistance to interference.
INS-aided GPS Tracking
INS-aided GPS Tracking
Ensure constant tracking in the area with poor GPS signal or even without it.
IP66 Dust & Water Resistance
IP66 Dust & Water Resistance
Waterproof case makes it easy to deploy on roof panels, providing better signal acquisition and continued optimal performance no matter the weather.
Driving Behavior Analysis (Basic)
Driving Behavior Analysis
Receive alerts when any of 4 kinds of dangerous driving behavior is detected.
Remote Cut-Off (Fuel_Power)
Remote Cut-Off (Fuel/Power)
Immobilize a vehicle by cutting off its power source/fuel supply via an installed relay.
Accurate Positioning
Accurate Positioning
Get accurate information about your car's movements even in areas with weak GPS signals.
RS232 & TTL Interface、TTL Interface
TTL Interface
Able to connect with different accessories for feature expansions.
GNSS
Positioning system GPS/BDS/GLONASS/Galileo + INS (inertial navigation system)
Frequency L1+L5
Positioning accuracy <1.5m CEP
Tracking sensitivity -165dBm
Acquisition sensitivity -148dBm
TTFF (open sky) Avg. hot start ≤1sec
Avg. cold start ≤24sec
Cellular
Communication network LTE Cat 1/GSM
Frequency VL101G (E)
LTE-FDD: B1/B3/B7/B8/B20/B28
LTE-TDD: B34/B38/B39/B40/B41
GSM: 850/900/1800/1900 MHz
VL101G (L)
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28
GSM: 850/900/1800/1900 MHz
Power
Battery 450mAh/3.7V industrial-grade Li-Polymer battery
Input voltage 3-36VDC
Interface
LED indication GNSS (Blue), Cellular (Green), Power (Red)
SIM Micro-SIM
Data storage 128+128Mb
Digital inputs Support
Digital outputs Support
Physical specification
Dimensions 70.0 x 80.0 x 25.0mm
Weight 113g
Operating environment
Operating temperature –20℃ to +70℃
Operating humidity 5%~95%, non-condensing
IP rating IP66
Feature
Sensors Accelerometer and gyroscope
Scenarios Vehicle movement alert, Speeding alert, Geo-fence entry/exit, Vehicle battery detection
Driving behavior analysis Harsh acceleration, Harsh braking, Harsh cornering, Sudden lane change

* We reserve the right to the final interpretation for this product. All information is for reference only and is subject to change without further notice.

APPLICATIONS
Vehicle Rental
Fleet Management
Usage-based Insurance
APPLICATIONS
Vehicle Rental
Fleet Management
Usage-based Insurance
