INS-aided GPS Tracker

The JM-VG01U is an advanced vehicle tracking device with great analytical capacity. With a 3-axis accelerometer and 3-axis gyroscope, it can detect 8 types of improper driving behaviors. Automatic computing based on an algorithm ensures the vehicle location even in non-GPS area. Its flexible and improved alert system increases safety and security while effectively reducing false alerts ratio.

INS-aided GPS Tracking

INS-aided GPS Tracking Ensures constant tracking in the area with poor GPS signal or even without it.

Driving Behavior Analysis (Advanced)

Driving Behavior Analysis (Advanced) Acceleration, braking, cornering, sudden lane change, collision, skidding, rollover, roll & pitch.

Mileage Accuracy >=98%

Mileage Accuracy >=98% Precise mileage calculation based on a unique algorithm, the mileage error can be less than 2%.

Ignition detection

Ignition detection Always keeps you informed of the ACC status of your vehicle.

6-axis Accelerometer & Gyroscope

6-axis Accelerometer & Gyroscope Sensitive detection of linear acceleration and angular velocity.

Remote cut-off (optional)

Remote cut-off (optional)

Panic button

Panic button A button close to driver allowing him to ask for immediate help with just a single press.

IP65 Dust & Water Resistance

IP65 Dust & Water Resistance Rugged and reliable design ensures stable operation in tough conditions.

Application Areas

Auto Finance
Fleet Management4
Usage-based Insurance

GNSS
Positioning system	GPS, GLONASS, GALILEO
Frequency	L1
Positioning accuracy	<10 meters
Track sensitivity	-165dBm
Acquisition sensitivity	-148dBm
TTFF (open sky)	Avg. hot start ≤1sec
TTFF (open sky)	Avg. cold start ≤32sec
Cellular
Communication network	GSM
Frequency	Quad-band 850/900/1800/1900 MHz
Power
Battery	450mAh/3.7V industrial-grade Li-Polymer battery
Input voltage	9-36VDC
Interface
LED indication	GNSS (Blue), Cellular (Green), Power (Red)
SIM	Micro-SIM
Data storage	32+32Mb
Digital inputs	ACC, SOS
Digital outputs	Relay
Physical specification
Dimensions	80.0 x 67.0 x 16.0 mm
Weight	63g
Operating environment
Operating temperature	–20℃ to +70℃
Operating humidity	5%～95%, non-condensing
IP rating	IP65
Feature
Voice monitoring range	≤5 meters
Sensors	Accelerometer and gyroscope
Scenarios	Vibration alert, Vehicle movement alert, Over-speed alert, Geo-fence, SOS call, Power supply disconnection
Driving behavior analysis	Harsh acceleration, Harsh braking, Harsh cornering, Sudden lane change, Collision, Skidding, Rollover, Roll & pitch

Standard Accessory

Hook and loop fastener Relay

Relay

Panic button

Power Cable

User Manual	PDF
Leaflet	PDF
